Pontiac Fiero Component locations such as the Ignition module, Fuel pump relay, etc

A/C Compressor Relay - Under engine cover, driver side, upper firewall, mounted in relay block.

Blower Motor - Hi / Low Relay - Front seating area, center, behind dash, passenger side of A/C controls, mounted in relay block. Application:Blower (high)

Blower Motor Relay - Trunk area, passenger side, rear of wheel-well, mounted in corner of trunk area.

Control Module-Ignition - Front seating area, center, under console.

Coolant Temperature Sensor - Under engine cover, passenger side, upper engine area, front of water outlet, passenger side of cold start switch, mounted in intake manifold.

EGR Position Sensor - NA

EGR Valve - Under engine cover, driver side upper engine area, above trans-axle, next to distributor, mounted on engine block.

Engine Control Computer - Rear seating area, center, upper firewall, mounted between seats, behind console.

Engine Temperature Sensor -NA

Flasher - Hazard flasher - Front seating area, passenger side, under dash, passenger side of heater - A/C assembly, mounted in convenience center Application:Hazard flasher.

Flasher Turn signal - Front seating area, driver side, under dash, mounted on driver side of steering column. Application:Turn signal.

Fuel Filter - Under hood, center, upper engine area, driver side of engine block, mounted in fuel line.

Fuel Pump Relay - Under engine cover, driver side, upper firewall, mounted on firewall.

Horn Relay - Front seating area, passenger side, behind dash, front driver side of relay block, mounted behind upper dash panel.

Knock Sensor - NA

MAP Sensor - Under engine cover, center, upper engine area, mounted on passenger side of air intake manifold.

Mass Air Flow Sensor - NA

OBD Diagnostic Link Connector - Front seating area, center, under console.

Oil Pressure Switch - Under engine cover, passenger side, upper engine area, mounted in block, approximately (3) inches above water pump.

Oxygen Sensor - Under engine cover, driver side, lower engine area, mounted on exhaust manifold pipe.

PCV Valve - Under hood, center, upper engine area, mounted in front valve cover.

Power Door Lock Relay - Front seating area, passenger side, under dash, mounted behind kick panel.

Radiator Cooling Fan Motor Relay - Under engine cover, driver side, upper firewall, mounted in relay block.

Rear Window Defroster Relay - Front seating area, driver side, under dash, above brake pedal, next to stoplight switch, mounted on support bracket.

Thermostat - Under engine cover, center, upper engine area, mounted under filler cap inside thermostat housing.

Throttle Position Sensor - Under engine cover, center, upper engine area, mounted on driver side rear of throttle valve assembly.

Vehicle Speed Sensor - Mounted on transmission
